6" Oval Split-Color Amber/White Grommet Mount Flashing Warning, 28 Patterns
SKU: M63201YWCL
6" Oval Split-Color Amber/White Grommet Mount Flashing Warning, 28 Patterns
The Maxxima M63201YWCL is a high-output, split-color amber/white 6" oval LED warning light designed for maximum visibility and versatility across a wide range of fleet, utility, and work truck applications. Equipped with 24 bright LEDs—12 amber and 12 white—it delivers 28 programmable flash patterns with the flexibility to operate each color independently. This dual-voltage model fits standard 6" oval grommet mounts and connects via an integrated PL-3 plug with two additional control wires. SAE J595 Class 1 & J593 compliant, the M63201YWCL is an ideal solution for scene lighting, directional alerts, or dual-purpose warning configurations, and is backed by Maxxima’s 5-year warranty for long-term performance.
FEATURES & BENEFITS
- Fits Standard 6” Oval Grommet (M50600-B Sold Separately)
- 28 Programmable Flash Patterns
- Ability to Operate Colors Individually
- 12/24 VDC Dual Voltage
- SAE J593
- 5 Year Warranty
SPECIFICATIONS
- Voltage: 12/24 VDC
- Amp Draw: 0.9A Max 12V / 0.9A Max 24V
- Dimensions: 6.3”W x 2.2”H x 1.2”D
- Mounting: 6” Oval Grommet
- Connector: Integrated PL-3 +2 Wires, 1.1”
- LEDs: 24 (12 of Each Color)
- Legal Heading: W-1M, R
- DOT/SAE: J593, J595 Class 1
| Freightliner | Argosy, Cascadia, Cascadia 113, Cascadia 125, Century, Classic, COE, Columbia, Coronado, FL106, FL112, FL50, FL60, FL70, FL80, FLA, FLC, FLD112, FLD112 (Set back Axle), FLD120, FLD120 SD, FLD132, M2, M2 106 |
| Kenworth | C500, K100, K300, T170, T2000, T270, T300, T370, T400, T450, T600, T660, T680, T700, T800, T880, W900, W900A, W900B, W900L, W990 |
| Peterbilt | 320, 325, 330, 335, 337, 348, 357, 359, 362, 365, 367, 375, 376, 377, 378, 379, 384, 386, 387, 388, 389, 567, 579, 587 |
| International | 1452FC, 1452SC, 1652SC, 1652UPS, 2554, 2574, 2575, 2654, 2674, 2675, 3000, 3800, 4000, 4100, 4100 SBA, 4200, 4200 LP, 4300, 4300 LP, 4400, 4400 LP, 4600, 4600 LP, 4600 UH, 4700, 4700 LP, 4700 LPX, 4800, 4900, 5500i, 5600i, 5900i, 7100, 7300, 7600, 8100, 8200, 8300, 9200, 9200i SBA, 9300, 9400, 9400i SBA, 9600, 9670, 9700, 9800, 9800 SBA, 9800 SFA, 9900, CE200, CE300, LoneStar, LT Series, Paystar 5900, Prostar, TranStar 8500 &8600, Workstar 7600 &7700 |
| Volvo | VN, VN2, VNL, VNM, WIA & White GMC |
| Mack | CH, CHN, CV, CXN, Granite, Pinnacle (Vision Elite), R600 & R700, RD, RH, Vision |
