Rolling Lobe Air Spring with Aluminum Base, Replaces Firestone
SKU: US30-8709-01
Rolling Lobe Air Spring with Aluminum Base, Replaces Firestone
Out Of Stock
Specifications
Air Spring Type:
Rolling Lobe
Base Plate Material:
Aluminum
Bottom Configuration:
2.25" C/C
Bottom Plate Bolt Hole Quantity:
1
Bottom Plate Diameter:
9.17
Bottom Plate to Top Plate Mounting Alignment:
Parallel
Compressed Length:
6
Extended Length:
19.4
Load Rating at 100 PSI:
9250
Load Rating at 80 PSI:
7400
Maximum Diameter:
10.62
Prop 65 - Long Label:
WARNING: Reproductive Harm - www.p65warnings.ca.gov
Prop 65 - Short Label:
WARNING: Cancer - www.p65warnings.ca.gov
Prop 65 Y/N:
N
Top Plate Bolt Hole Quantity:
2
Top Plate Diameter:
10.38
Top Plate Mounting/Fitting Configuration:
5.5" C/C
| Freightliner | Argosy, Cascadia, Cascadia 113, Cascadia 125, Century, Classic, COE, Columbia, Coronado, FL106, FL112, FL50, FL60, FL70, FL80, FLA, FLC, FLD112, FLD112 (Set back Axle), FLD120, FLD120 SD, FLD132, International MV, M2, M2 106 |
| Kenworth | C500, K100, K300, T170, T2000, T270, T300, T370, T400, T450, T600, T660, T680, T700, T800, T880, W900, W900A, W900B, W900L, W990 |
| Peterbilt | 320, 325, 330, 335, 337, 348, 357, 359, 362, 365, 367, 375, 376, 377, 378, 379, 384, 386, 387, 388, 389, 567, 579, 587 |
| International | 1452FC, 1452SC, 1652SC, 1652UPS, 2554, 2574, 2575, 2654, 2674, 2675, 3000, 3800, 4000, 4100, 4100 SBA, 4200, 4200 LP, 4300, 4300 LP, 4400, 4400 LP, 4600, 4600 LP, 4600 UH, 4700, 4700 LP, 4700 LPX, 4800, 4900, 5500i, 5600i, 5900i, 7100, 7300, 7600, 8100, 8200, 8300, 9200, 9200i SBA, 9300, 9400, 9400i SBA, 9600, 9670, 9700, 9800, 9800 SBA, 9800 SFA, 9900, CE200, CE300, LoneStar, LT Series, MV, Paystar 5900, Prostar, TranStar 8500 &8600, Workstar 7600 &7700 |
| Volvo | VN, VN2, VNL, VNM, WIA & White GMC |
| Mack | CH, CHN, CV, CXN, Granite, MD, Pinnacle (Vision Elite), R600 & R700, RD, RH, Vision |
