Suspension - Leaf Spring Leaf Spring Fits Hendrickson
SKU: 62-1092
Suspension - Leaf Spring Leaf Spring Fits Hendrickson
Out Of Stock
SpecificationsAxle Modification Needed | No
Axle Orientation | Front
Bushing Color | Gray
Bushings Included | Yes
Center Hole | 1/2 in
Color | Black
End 1 Attachment Type | Up Turned Eye
End 2 Attachment Type | Up Turned Eye
Grading | PD/401 PD/423 2/590 5/527 1/499
Helper Spring | No
LE End Type/Bushing No | STD/TB-78
Leaf Quantity | 8
Leaf Spring Arch Length | 4.25 in
Leaf Width | 4 in
Length Axis 1 | 26.125 in
Length Axis 2 | 26.375 in
Load Rate | 9300 lb
Long End Bushing Type | Threaded
Long End Pin Diameter | M32 x 4.0
Material | Steel
Mounting Hardware Included | No
Number of Leaves | 2PD/8
Pack Thickness | 5.945 in
Package Contents | 1 Leaf Spring
Part Number | 62-1092
Part Type | Suspension - Leaf Spring
PL-1 | 96-1330-1
PL-2 | 96-1330-2
SE End Type/Bushing No | STD/TB-78
Short End Bushing Type | Threaded
Short End Pin Diameter | M32 x 4.0
Spring Design | Eyes Both Ends
Spring Research Institute Number | 62-1092
Spring Type | Leaf Spring
Suspension Grade Type | Standard
Weight | 190.100000
| Freightliner | Argosy, Cascadia, Cascadia 113, Cascadia 125, Century, Classic, COE, Columbia, Coronado, FL106, FL112, FL50, FL60, FL70, FL80, FLA, FLC, FLD112, FLD112 (Set back Axle), FLD120, FLD120 SD, FLD132, International MV, M2, M2 106 |
| Kenworth | C500, K100, K300, T170, T2000, T270, T300, T370, T400, T450, T600, T660, T680, T700, T800, T880, W900, W900A, W900B, W900L, W990 |
| Peterbilt | 320, 325, 330, 335, 337, 348, 357, 359, 362, 365, 367, 375, 376, 377, 378, 379, 384, 386, 387, 388, 389, 567, 579, 587 |
| International | 1452FC, 1452SC, 1652SC, 1652UPS, 2554, 2574, 2575, 2654, 2674, 2675, 3000, 3800, 4000, 4100, 4100 SBA, 4200, 4200 LP, 4300, 4300 LP, 4400, 4400 LP, 4600, 4600 LP, 4600 UH, 4700, 4700 LP, 4700 LPX, 4800, 4900, 5500i, 5600i, 5900i, 7100, 7300, 7600, 8100, 8200, 8300, 9200, 9200i SBA, 9300, 9400, 9400i SBA, 9600, 9670, 9700, 9800, 9800 SBA, 9800 SFA, 9900, CE200, CE300, LoneStar, LT Series, MV, Paystar 5900, Prostar, TranStar 8500 &8600, Workstar 7600 &7700 |
| Volvo | VN, VN2, VNL, VNM, WIA & White GMC |
| Mack | CH, CHN, CV, CXN, Granite, MD, Pinnacle (Vision Elite), R600 & R700, RD, RH, Vision |
